Flanged ball check valve (BKF) PN10/16

Kolk ball check valves are made of ductile iron GJS-400/500 (DIN1693 GGG-40/50). Face to face acc. to DIN 3202-F6, flange drilling acc. to EN 1092-2 (ISO 7005-2). Epoxy coated (Resicoat®) acc. to EN 14901 (DIN 30677-2) and GSK certified (RAL-GZ 662). Sinking ball type and upto DN 300 NBR covered iron ball over DN 300 massive PU ball. Floating ball can be delivered upon request.

Download Datasheet

Advice from our experts?

+31 (0)74 - 291 89 61

info@kolkbv.nl

Call me back

Experience since 1922
Flexible and reliable
Inhouse production and coating
Wide range of products on stock
Customized Products and Service

Compare selected items

Add selected items to quote

Sort	Article	PN	ø DN [mm]	L [mm]	H [mm]	ø M [mm]	KG
0	BKF 50	PN10	50	200	100	60	7
1	BKF 65	PN10	65	230	145	95	11
2	BKF 80	PN10	80	260	145	95	12
3	BKF 100	PN10	100	300	175	120	18
4	BKF 125	PN10	125	350	250	175	30
5	BKF 150	PN10	150	400	250	175	35
6	BKF 200	PN10	200	500	330	240	69
6	BKF 250	PN10	250	600	400	300	116
7	BKF 300	PN10	300	700	470	360	184
8	BKF 350	PN10	350	800	570	420	280
9	BKF 400	PN10	400	900	655	480	415
10	BKF 450	PN10	450	1000	655	480	650
11	BKF 500	PN10	500	1100	840	600	745
12	BKF 600	PN10	600	1200	950	720	910
13	BKF 200	PN16	200	500	330	240	69
14	BKF 250	PN16	250	600	400	300	116
15	BKF 300	PN16	300	700	470	360	184
16	BKF 350	PN16	350	800	570	420	290
17	BKF 400	PN16	400	900	655	480	430
18	BKF 450	PN16	450	1000	655	480	670
19	BKF 500	PN16	500	1100	840	600	770
20	BKF 600	PN16	600	1200	950	720	940
